OLED Test Blade Pin

  • Test Socket for Display Parts Inspection

  • Possible to inspect fine pitch (300㎛)

  • Positioning accuracy (±10㎛)

  • Low-resistance probes of 60 mΩ or less


Smartphone Main PCB inspection socket

  • Align Blade Pins at Fine Spaces

  • Socket for inspection of random array structure

  • Fine pitch inspection possible

  • Random array, 20 GHz frequency characteristic

img_main_pcb_test socket.png
img_main_pcb_test socket_1.png

Socket for Smartphone Camera inspection

  • Blade Pin Electrical Characteristics: Resistance of 60mΩ or less

  • Frequency characteristics of blade pin: signal transfer characteristics over 10GHz

  • Measurement of position accuracy of aligned pins: position tolerance range within ±10μm

  • Socket durability evaluation: life of more than 100,000 times


Socket for checking data transmission

  • Fine pitch inspection possible

  • Positioning accuracy (±10㎛)

  • 40GHz frequency characteristics

  • Low-resistance probes of 50mΩ or less

Top view


Bottom  view


Blade pin with high current characteristics

  • 3A high current conduction possible

  • OD 0.05mm

img_blade pin.png

Rubber Socket

  • Minimum Pitch : 0.25mm

  • Normal Height : 0.8~1.1mm

Rubber Only

Rubber + PI Film


Socket Assembly

  • ​ This is assembled with rubber socket inside Housing.

  • For BGA Test
